PRODUCT FAMILY CODE

SCP

SIZES

• 1,000lt IBC



APPLICATIONS

FEATURES

• Polyethylene outer bund construction ensures compatability with a very wide range of chemicals
• APR  (PE composite) inner frame provides equal protection from the same range of chemicals
• Frame is designed to safe working load of 2,600 kg allowing the heaviest chemicals to be stored. (Routinely, 98% sulphuric acid is stored in these units)
• UV polyethylene is used in the manufacturing process to allow the units to be operated in direct sunlight without fear of degradation
• Elevated frame allows IBC to be easily placed on the platform by a standard fork lift
• 275lt buffer tanks can optionally be supplied as day tanks for dosing pumps or stock buffer tanks

 STANDARD EQUIPMENT

• PE outer spill containment

• Internal APR frame
• 50mm drain plug
• Discharge: 1″ ball valve c/w camlock
• Fill: 1″ ball valve c/w camlock
• Vent: 2″ Pipe rising above the height of the IBC and returning into the bund Materials

OPTIONS EQUIPMENT & SERVICES

• Fully configured buffer tank, including inlet, outlet, vent
• Sight glass
• Dry break couplings
• IBC tie down straps
• IBC UV cover
• IBC to tank hose
• Hose park
• Integral skids
• Lute pot
• Cover for external use
• Full integration with dosing pumps and other delivery systems. (See Chemical Dosing System on this web site)
